| 1.Display mode | High-definition 8.4” TFT color LCD screen display |
| 2.Ventilation mode | IPPV, MANUAL (Manual monitoring of tidal volume, ventilation volume, respiratory rate) |
| 3.Ventilation parameters | Tidal volume 20~1500ml |
| Rate 1~99 bpm |
SIMV rate 2~20 bpm |
| I:E 4:1~1:8 |
Inspiratory trigger pressure -1.0~2.0 kPa |
PEEP 0~2.0 kPa |
Pressure range 1.0~6.0 kPa |
SIGH 1.5 times the inspiratory time (70-150 adjustable) |
Inspiratory platform 0~50% |
| 4.Parameters for ventilation monitoring | tidal volume, ventilation volume, IPPV rate, SIMV rate, total respiratory rate, I/E, peak pressure of airway, average pressure, pressure - time waveform, flow rate - time waveform,PEEP,inspiratory trigger pressure. |
| 5.Monitoring of oxygen concentration | 21%~100% |
6.Security Alarm System | Airway Pressure alarm | upper limit setting range | 1.0~6.0kPa |
| low limit setting range | 0.2~5.0kPa |
Oxygen Concentration alarm | upper limit setting range | 21%-100% |
| low limit setting range | 10%-80% |
Per-minute ventilation volume alarm | upper limit setting range | 3.0~30L/min |
| low limit setting range | 1.0~10L/min |
| Sustained high-pressure alarm | it will give alarm when stress have consistently been higher than 2.5 kPa |
| Suffocation alarm | it will give sound and light alarm if there is no tidal volume input for 15 second. |
| Power alarm | |
| 7.Power | AC 220V±10% 50Hz±1Hz |
