Feature:
1. Indicator light indicates working state
2. Over-temperature & over-pressure auto-protection device
3. Double scale indication pressure gauge
4. Safe protection of water lacking
5. With the below exhaust structure,which is convenient to exhaust the cold air
6. Automatically shut off with beep reminding after sterilization
7. Fully stainless steel structure
8. Easy to operate,safe and reliable
9. With two stainless steel sterilizing baskets
MODEL Technical Data | LS-35LJ | LS-50LJ | LS-75LJ | LS-100LJ | LS-120LJ | LS-150LJ |
Chamber volume | 35L
φ318×450m | 50L
φ340×5550 | 75L
φ400×600mm | 100L
φ440×650mm | 120L φ480×660mm | 150L φ510×740mm |
Working pressure | 0.22MPa |
Working temperature | 134℃ |
Max. working pressure | 0.23 Mpa |
Heat average | ≤±1℃ |
Timer scope | 0～60min |
Temperature Adjustment | 105～134℃ |
Power | 2.5KW/AC2220V,50Hz | 3KW/AC2220V,50Hz | 4.5KW/AC2220V,50Hz | 6KW/AC220V.50Hz |
Overall dimension | 480×460×850mm | 520×520×980mm | 560×560×980mm | 590×590×1080mm | 600×640×1140mm | 670×690×1130(mm |
Transport dimension | 570×550×970(mm) | 590×590×1110(mm) | 650×630×1150(mm) | 680×650×1220(mm) | 730×730×1270(mm) | 760×760×1270(mm) |
G.W/N.W | 56Kg/ 42Kg | 68Kg/ 50Kg | 90Kg/ 70Kg | 105Kg/ 85Kg | 125Kg/ 100Kg | 135Kg/110Kg |
Details:
