| Vertical lift | 250-600mm |
| Motor power | 100W |
| The activity range of Horizontal arm | ( radius) 1000mm |
| Horizontal arm and functional box can be simultaneously rotated | 340 ° |
| The gas terminal interface standard configuration | oxygen 1 pc; suction 1 pc; air 1 pc; nitrogen 1 pc; CO2 1 pc; nitrous oxide; waste gas 1 pc |
| Different colors and shapes, with anti-pick wrong function |
| more than 20,000 times mating cycles |
| using the secondary seal, with three states (on, off, pull), can carry air service |
| Instrument platform | One layer (height adjustable); rounded bumper design, each platform can load 30kg |
| weight loading | 150kg |
| Power supply | AC220V, 50HZ; AC110V, 60HZ |
| Electrical outlet | 8 pcs (220V / 10A) |
| Potential ground terminal | 2 pcs |
| The network interface | RJ45 1 pc |
| Drawer | Wet section, 1 pc |
| Dry Section, 1 pc |
| Syringe pump rack | 1 pc |
| Infusion pump rack | 1 pc |
| The main material | high-strength aluminum alloy |
| The surface treatment | using imported high-voltage electrostatic powder spray |
| Fixing | Ceiling-mounted, high stability |
