Manual Patient Lift with basic sling
Lifting by hand, with emergency lifting stop switch
150kg load capacity
With hand control
Easy to operate
Sling is basic standard sling, and if you need extra sling, we also can make it based user condition, different models slings optional.
| Specification: |
| Frame material: | Strong steel frame |
| Coating: | Powder coating |
| Front caster: | 3" |
| Rear caster | 4" with brake |
| Controller: | Hand lift : up and down |
| Switch: | With emergency lifting stop switch |
| Arm length: | 1100mm /43.4" |
| Overall width: | 585mm / 23" |
| Leg extend width: | 800mm / 31.5" |
| Lifting range: | 740mm-1770mm / 19"-70" |
| Push hand height | 1130mm / 44.49" |
| Leg height | 120mm / 4.72" |
| Weight capicity | 150kg |
| Net weight | 40kg |
| Packing: | 1pc/ carton 1170*690*270mm |
| |
| 20'FCL/ 40'FCL/ 40'HQ | 150 /310/ 340 PCS |
| Lead time | normal type we have stock. |
| Shiping advise: | By sea, at least 5 pcs to save shipping cost |
| |
Detailed picture:
The packing is carton for 1 pcs.
