Model
technical data | ROC05-TM-XB20J | ROC05-TM-XB24J |
| Sterilizing chamber volume | 20L(φ250×420 mm) | 24L(φ250×520 mm) |
| Maximum working pressure | 0.22Mpa |
| Maximum working temperature | 134oC |
| Adjustment of temperature | 105-134oC |
| Timer | 0-60 min |
| Chamber temperature equal | ≤ ± 1oC |
| Source power | 1.5KW/AC 220V 50Hz (AC110V 60HZ) |
| Sterilizing plate | 340×200×30 mm (3 piece) | 400×200×30 mm (3 piece) |
| Dimension | 480×480×384 mm | 580×480×384 mm |
| G.W/N.W | 44/40KG | 50/45KG |
| Package dimension | 700×580×500 mm | 800×580×500 mm |
